Description
The ConSole+ provides an angle of 15 degrees and can be fitted to flat roofs with a pitch of up to 5 degrees. Most commercially available framed standard PV modules fit on the ConSole.
The ConSole is weighed down with ballast. Any material can be used: gravel, paving slabs, bricks, rocks etc. The amount of ballast depends on the height and location of the building.
Mounting components are included for framed PV-modules. The modules attach to the mounts using the mounting holes on the back of the module. Please check the measurements below against your panel specification:
Max module length: 1550-2150 mm
Holes gap – width: 895-1014 mm
Holes gap – length: 690-1180 mm
Note: The hole gap should be given on the panel datasheet in a form similar to the picture below.
